GM-20 double glue machine
Structural features:
★after quenched of the glue roller surface,the hole machining, surface grinding and doing balancing engraved anilox pit type, coating evenly, less consumption of plastic
★glue roller turns is controlled by the frequency motor,by inverter control ensures glue roller line speed synchronous machine with double machine,they can operate independently.
★electric adjustment display the glue amount.Automatic cycle for glue, glue avoid sedimentation, viscosity stability.
technical parameters:
1.temperature range of the preheater:150—200℃ 2,steam pressure:1.12—1.3Mpa
3,air source system:0.4—0.9Mpa
Mainly purchased parts, raw materials and origin:
| Name of main parts | Brands or place of origin | material |
| Glue roller and Fixed paste roller | Tiangang | 45Quenching steel |
| Preheat roller | Tiangang or jigang | Q235B container board |
| bearing | HRB,ZWZ,LYC | |
| Sear belt bearing | Zhejiang wuhuan | |
| Pneumatic elements | Zhejiang sonorCSM | |
| contacts | France Schneider | |
| Air switch | France Schneider | |
| button | Chint | |
| Adjust glue reducer | Taiwan chengbang | |
| Main reducer | Tanwan chengbang | |
| Touch screen | Taiwan WEINVIEW or MCGS | |
| PLC and frequency machine | Taiwan delta | |
| belt | German OPTIBELT | |
| traps | Beijing | |
| Lose glue dispensing pumps | Hebei botou | |
SM-F type double facer
Structural features:
★Heating plate surface by grinding treatment,hot plate width600mm,a total of 16 pieces heating plate,Cooling stereotypes Department 4 m.
Preheat board is made of contacts board, in accordance with the national standard of pressure container, enclosed the pressure container certificate and inspection certificate.
★hot plate internal for partition isolation structure,s-shaped flow of steam,Steam, water separation function significantly improves the utilization of steam.
